Ideal for package transport, sorting, or picking - Dual platform boosts efficiency for split loads - Compact design allows easy navigation in tight warehouse spaces - Low-noise wheels, floor-friendly, suited for frequent movement
Real-world operational challenges solved through custom sheet metal engineering, space-saving geometry, and workflow optimization.
Moving smaller carton boxes, loose mail sacks, or split parcels on open-frame carts leads to items sagging or tumbling through structural gaps, while high platforms cause lumbar strain.
Target Deployment: Intra-facility parcel sorting hubs, retail logistics sorting centers, and light-to-medium carton transport lines.
Continuous Solid CR Sheet Deck: Fabricated from smooth cold-rolled (CR) steel sheet reinforced underneath by 25×25×2 mm MS box tubes and 40×40×3 mm angle trusses, ensuring split parcels and small boxes sit completely flat without slipping through gaps.
Ergonomic 275 mm Low-Lift Profile: Platform height is maintained at 275 mm from the ground, providing an optimal ergonomic transfer plane that reduces lower-back bending strain during heavy carton offloading.
Engineered to strict industrial manufacturing tolerances with complete raw material mill test traceability.
| Product Name | L Cart |
|---|---|
| Overall Dimensions | 1260 mm (H) x 1400 mm (W) x 625 mm (D) |
| Carrying Capacity / Load | Up to 300 - 350 Kgs |
| Raw Material Grade | MS CRCA/HR/HRPO |
| Surface Finish & Coating | Powder-coated (Ivory RAL 9016, texture) for durability |
| Structure | Manufactured from MS box pipe (25x25x2 mm) frame, MS angle (40x40x3 mm) reinforcement; top guard MS pipe (Dia 28 mm), CR Sheet; robust platform |
| Wheels | 6 Caster Wheels: 4 x Swivel with brake, 2 x Fixed |
| Platform Height | ~275 mm (ground to top of lower deck) |
| Handle | Dual ergonomic handles, 28 mm diameter |
| Additional Features | Bolted construction for solid rigidity; top guard on both platforms for securing items |
| Functional Features | Ideal for package transport, sorting, or picking - Dual platform boosts efficiency for split loads - Compact design allows easy navigation in tight warehouse spaces - Low-noise wheels, floor-friendly, suited for frequent movement |
Key technical, compliance, and sourcing answers for engineering teams, facility managers, and B2B procurement leads.
The L Cart manufactured by Sameta Metal Pro features a verified load rating of Up to 300 - 350 Kgs, nominal dimensions of 1260 mm (H) x 1400 mm (W) x 625 mm (D), and is fabricated from certified MS CRCA/HR/HRPO with Powder-coated (Ivory RAL 9016, texture) for durability. All joints are welded conforming to AWS D1.1 and IS 817 standards for rugged industrial durability.
Fabricated exclusively from prime certified steel with 100% Mill Test Certificate (MTC) heat traceability. Parts are processed on high-precision CNC fiber lasers (±0.1 mm) and multi-axis CNC press brakes (±0.2 mm / ±0.5°) adhering to ISO 2768-m. Surface protection features an automated 9-stage chemical pre-treatment with zinc/iron phosphating and conveyorized powder coating (60–80μ DFT) tested to 500+ hours of ASTM salt spray resistance.
Yes. As a turnkey contract manufacturer operating a 60,000 sq. ft. facility in Chennai, India, we support complete custom engineering. We can adjust dimensions, modify caster or hitch configurations, add RFID/barcode brackets, apply custom corporate RAL powder shades, and laser-mark customer asset tags. Our engineering team provides 3D CAD modeling and DFM analysis within 24–48 hours.
Production lead times typically range from 2 to 4 weeks depending on batch volume, with first-article prototype sampling delivered in 5–7 business days. We accommodate flexible Minimum Order Quantities (MOQs) for pilot testing up to multi-container enterprise rollouts. For global exports, products are packed in ISPM-15 heat-treated fumigated wooden crates with VCI anti-rust barrier wrapping, situated just 40 km from Chennai Port for streamlined ocean freight to North America, Europe, and the Middle East.
