Multi-tier for organized sorting - Raised edge stoppers prevent items from falling - Compact footprint for narrow aisles - Ideal for batch picking and order consolidation
Real-world operational challenges solved through custom sheet metal engineering, space-saving geometry, and workflow optimization.
During high-speed batch picking in narrow fulfillment aisles, sharp turns and sudden stops cause loose packages and pick bins to slide off open shelves, cross-contaminating orders and ruining sort accuracy.
Target Deployment: Narrow-aisle fulfillment centers, e-commerce batch-picking zones, and mezzanine storage racks.
Raised Anti-Spill Shelf Lips: Each of the three steel shelf decks is fabricated with precision-bent front retaining lips. These raised edge barriers stop loose items and pick bins from sliding forward during rapid turns and sudden stops.
Compact Narrow-Aisle Enclosure: Three-sided welded wire mesh cladding secures items from rear and side falls, housed within an ultra-compact chassis engineered for smooth maneuverability through narrow rack aisles.
Engineered to strict industrial manufacturing tolerances with complete raw material mill test traceability.
| Product Name | Caged Pick and Stow Cart |
|---|---|
| Overall Dimensions | 1500 mm (H) x 900 mm (W) x 600 mm (D) |
| Carrying Capacity / Load | Up to 360 Kgs |
| Raw Material Grade | MS CRCA/HR/HRPO |
| Surface Finish & Coating | EPOXY POWDER |
| Structure | Three-level wire mesh cage with metal shelves |
| Shelf Load Capacity | 90 Kg per shelf |
| Functional Features | Multi-tier for organized sorting - Raised edge stoppers prevent items from falling - Compact footprint for narrow aisles - Ideal for batch picking and order consolidation |
Key technical, compliance, and sourcing answers for engineering teams, facility managers, and B2B procurement leads.
The Caged Pick and Stow Cart manufactured by Sameta Metal Pro features a verified load rating of Up to 360 Kgs, nominal dimensions of 1500 mm (H) x 900 mm (W) x 600 mm (D), and is fabricated from certified MS CRCA/HR/HRPO with EPOXY POWDER. All joints are welded conforming to AWS D1.1 and IS 817 standards for rugged industrial durability.
Fabricated exclusively from prime certified steel with 100% Mill Test Certificate (MTC) heat traceability. Parts are processed on high-precision CNC fiber lasers (±0.1 mm) and multi-axis CNC press brakes (±0.2 mm / ±0.5°) adhering to ISO 2768-m. Surface protection features an automated 9-stage chemical pre-treatment with zinc/iron phosphating and conveyorized powder coating (60–80μ DFT) tested to 500+ hours of ASTM salt spray resistance.
Yes. As a turnkey contract manufacturer operating a 60,000 sq. ft. facility in Chennai, India, we support complete custom engineering. We can adjust dimensions, modify caster or hitch configurations, add RFID/barcode brackets, apply custom corporate RAL powder shades, and laser-mark customer asset tags. Our engineering team provides 3D CAD modeling and DFM analysis within 24–48 hours.
Production lead times typically range from 2 to 4 weeks depending on batch volume, with first-article prototype sampling delivered in 5–7 business days. We accommodate flexible Minimum Order Quantities (MOQs) for pilot testing up to multi-container enterprise rollouts. For global exports, products are packed in ISPM-15 heat-treated fumigated wooden crates with VCI anti-rust barrier wrapping, situated just 40 km from Chennai Port for streamlined ocean freight to North America, Europe, and the Middle East.
