Removable dividers allow custom compartment sizing - Enables batch/zone picking for multiple SKUs - Improves order picking speed, efficiency, and accuracy Mobile design aids movement through narrow warehouse aisles - Ideal for e-commerce, grocery, and high-SKU warehouses
Real-world operational challenges solved through custom sheet metal engineering, space-saving geometry, and workflow optimization.
Picking multiple customer orders simultaneously leads to SKU mixing, incorrect packaging, and costly pick-error rework when carts lack flexible internal compartmentalization.
Target Deployment: Multi-order batch picking, multi-SKU e-commerce order consolidation, and pharmaceutical distribution centers.
Modular Reconfigurable Mesh Dividers: Fitted with adjustable slotted wire mesh dividers that allow warehouse personnel to customize compartment dimensions on the fly to match varying SKU profiles and order batch sizes.
Multi-Zone Batch Pick Optimization: Organizes discrete customer orders into clear visual compartments, enabling pickers to fulfill multiple zone orders in a single pass while preventing order cross-contamination.
Engineered to strict industrial manufacturing tolerances with complete raw material mill test traceability.
| Product Name | Multi-Compartment Mesh Divider Cart |
|---|---|
| Overall Dimensions | 1850 mm (H) x 644 mm (W) x 1800 mm (D) |
| Carrying Capacity / Load | Up to 300-400 Kgs |
| Raw Material Grade | MS CRCA/HR/HRPO |
| Surface Finish & Coating | EPOXY POWDER |
| Structure | Heavy-duty wire mesh frame with multiple adjustable levels |
| Wheels | 6 Caster Wheels: 4 x Swivel with brake, 2 x Fixed |
| Functional Features | Removable dividers allow custom compartment sizing - Enables batch/zone picking for multiple SKUs - Improves order picking speed, efficiency, and accuracy Mobile design aids movement through narrow warehouse aisles - Ideal for e-commerce, grocery, and high-SKU warehouses |
Key technical, compliance, and sourcing answers for engineering teams, facility managers, and B2B procurement leads.
The Multi-Compartment Mesh Divider Cart manufactured by Sameta Metal Pro features a verified load rating of Up to 300-400 Kgs, nominal dimensions of 1850 mm (H) x 644 mm (W) x 1800 mm (D), and is fabricated from certified MS CRCA/HR/HRPO with EPOXY POWDER. All joints are welded conforming to AWS D1.1 and IS 817 standards for rugged industrial durability.
Fabricated exclusively from prime certified steel with 100% Mill Test Certificate (MTC) heat traceability. Parts are processed on high-precision CNC fiber lasers (±0.1 mm) and multi-axis CNC press brakes (±0.2 mm / ±0.5°) adhering to ISO 2768-m. Surface protection features an automated 9-stage chemical pre-treatment with zinc/iron phosphating and conveyorized powder coating (60–80μ DFT) tested to 500+ hours of ASTM salt spray resistance.
Yes. As a turnkey contract manufacturer operating a 60,000 sq. ft. facility in Chennai, India, we support complete custom engineering. We can adjust dimensions, modify caster or hitch configurations, add RFID/barcode brackets, apply custom corporate RAL powder shades, and laser-mark customer asset tags. Our engineering team provides 3D CAD modeling and DFM analysis within 24–48 hours.
Production lead times typically range from 2 to 4 weeks depending on batch volume, with first-article prototype sampling delivered in 5–7 business days. We accommodate flexible Minimum Order Quantities (MOQs) for pilot testing up to multi-container enterprise rollouts. For global exports, products are packed in ISPM-15 heat-treated fumigated wooden crates with VCI anti-rust barrier wrapping, situated just 40 km from Chennai Port for streamlined ocean freight to North America, Europe, and the Middle East.
